User’s Manual of GSD-1002M
Figure 4-11-2 Statics MAC Status page screenshot
The page includes the following fields:
Object Description
Th
is is the number for entries
 No.
The MAC address for the entry
.
 MAC Address
The VLAN ID for the entr
y.
 VLAN
Displa
y the current port.
 Port
 Delete
Click to delete static MAC status entry.
4.11.2 MAC Filtering
By filtering MAC address, the switch can easily filter the per-configured MAC address and reduce the un-safety. The Static MAC
Setting screens in Figure 4-11-3 & Figure 4-11-4 appear.
Figure 4-11-3 MAC Filtering Setting page screenshot
The page includes the following fields:
Object Description
Phy
sical address associated with this interface.
 MAC Address
Indicates the ID of this pa
rticular VLAN.
 VLAN (1~4096)
Buttons
: Click to add new MAC filtering setting.
268
