User’s Manual of GSD-1002M
4.7.4.2 MLD Static Group
The MLD Static Group configuration screens in Figure 4-7-24 & Figure 4-7-25 appear.
Figure 4-7-24 Add MLD Static Group page screenshot
The page includes the following fields:
Object Description
Select VLAN ID
for this drop down list.
 VLAN ID
The IP
address for a specific multicast service
 Group IP Address
Select port nu
mber for this drop down list.
 Member Ports
Buttons
: Click to add IGMP router port entry.
Figure 4-7-25 MLD Static Groups page screenshot
The page includes the following fields:
Object Description
Displa
y the current VLAN ID
 VLAN ID
 Group IPv6 Address
Display the current group IPv6 address
Displa
y the current member ports
 Member Ports
 Modify
Click
to edit parameter.
160
