User’s Manual of GSD-1002M
4.3.3 Bandwidth Utilization
The Bandwidth Utilization page displays the percentage of the total available bandwidth being used on the ports. Bandwith
utilization statistics can be viewed using a line graph. The Bandwidth Utilization screen in Figure 4-3-7 appears.
To view the port utilization, click on the Port Management folder and then the Bandwidth Utilization link:
Figure 4-3-7 Port Bandwidth Utilization page screenshot
The page includes the following fields:
Object Description
 Refresh Period
This shows the period interval between last and next refresh.
Options:
 2 sec
 5 sec
 10 sec
Allow
user to enable or disable this function
 IFG
74
