User’s Manual of GSD-1002M
The page includes the following fields:
Object Description
Save Configuration to
FLASH
Click to save the configuration. For more detailed information, please refer to the
chapter 4.1.2
Restore to Default
Click to reset switch in default parameter. For more detailed information, please
refer to the chapter 4.15.1
4.1.2 Configuration Manager
The system file folder contains configuration settings. The screen in Figure 4-1-7 appears.
Figure 4-1-7 Save Button screenshot
The page includes the following fields:
Object Description
Running Configuration
Refers to the running configuration sequence use in the switch. In switch, the
running configuration file stores in the RAM. In the current version, the running
configuration sequence running-config can be saved from the RAM to FLASH by
save “Source File = Running Configuration” to “Destination File = Startup
Configuration”, so that the running configuration sequence becomes the start
up configuration file, which is called configuration save. To prevent illicit file
upload and easier configuration, switch mandates the name of running
configuration file to be running-config.
Startup Configuration
Refers to the configuration sequence used in switch startup. Startup
configuration file stores in nonvolatile storage, corresponding to the so-called
configuration save. If the device supports multi-config file, name the configuration
file to be .cfg file, the default is startup.cfg. If the device does not support
multi-config file, mandates the name of startup configuration file to be
startup-config.
Backup Configuration
The backup configuration is empty in FLASH; please save the backup
configuration first by “Maintenance > Backup Manager”.
35
