Planet GSD-1002M User Manual

User’s Manual of GSD-1002M
Figure 4-8-11 IP Precedence Mapping page screenshot
The page includes the following fields:
Object Description
Displa
y the current CoS value
 IP Precedence
Displa
y the current mapping to queue
 Mapping to Queue
Displa
y the current queue value
 Queue
Displa
y the current mapping to IP Precedence
 Mapping to IP
Precedence
4.8.3 QoS Basic Mode
4.8.3.1 Global Settings
The Basic Mode Global Settings and QoS Information screen in Figure 4-8-12 & Figure 4-8-13 appear.
Figure 4-8-12 Basic Mode Global Settings page screenshot
181
