User’s Manual of GSD-1002M
4.10.5 IPv6-based ACL
This page shows the ACL status by different ACL users. Each row describes the ACE that is defined. It is a conflict if a specific
ACE is not applied to the hardware due to hardware limitations. IPv6-based ACL screens in Figure 4-10-9 & Figure 4-10-10
appear.
Figure 4-10-9 IPv6-based ACL page screenshot
The page includes the following fields:
Object Description
Create a na
med IPv6-based ACL list
ï‚· ACL Name
Buttons
: Click to add ACL name list.
Figure 4-10-10 ACL Table page screenshot
The page includes the following fields:
Object Description
ï‚· Delete
Click to delete ACL name entry.
4.10.6 IPv6-based ACE
An ACE consists of several parameters. Different parameter options are displayed depending on the frame type that you
selected. The IPv6-based ACE screens in Figure 4-10-11 & Figure 4-10-12 appear.
260
