anual of GSD-1002M
Figure 4-8-8
DSCP to Queue and Queue to DSCP Mapping page screenshot
The page includes the following fields:
Object
Description
Select Queue
value for this drop down list.
ï‚·
Queue
Select DSCP
value for this drop down list.
ï‚·
DSCP
Buttons
: Click to apply changes.
Figure 4-8-9
DSCP Mapping page screenshot
179
178
180
