User’s Manual of GSD-1002M
Figure 4-7-29 Dynamic Router Table page screenshot
The page includes the following fields:
Object Description
Displa
y the current VLAN ID.
 VLAN ID
Displa
y the current dynamic router ports
 Port
Displa
y the current expiry time
 Expiry Time (Sec)
Figure 4-7-30 Static Router Table page screenshot
The page includes the following fields:
Object Description
Displa
y the current VLAN ID.
 VLAN ID
Displa
y the current port mask.
 Port Mask
Figure 4-7-31 Forbidden Router Table page screenshot
The page includes the following fields:
Object Description
Displa
y the current VLAN ID.
 VLAN ID
Displa
y the current port mask.
 Port Mask
