Figure 4-6-11 CIST Port Status page screenshot
The page includes the following fields:
Object Description
The s
witch port number of the logical STP port.
 Port
Displa
y the current indentifier (Priority / Port ID).
 Indentifier (Priority /
Port ID)
Displa
y the current external path cost conf/oper.
 External Path Cost
Conf/Oper
Displa
y the current internal path cost/oper.
 Internal Path Cost
Conf/Oper
Displa
y the current designated root bridge.
 Designated Root
Bridge
Displa
y the current external root cost
 External Root Cost
 Regional Root Bridge
Display the current regional root bridge
Displa
y the current internal root cost
 Internal Root Cost
Displa
y the current designated bridge
 Designated Bridge
 Internal Port Path Cost
Display the current internal port path cost
 Edge Port Conf/Oper
Display the current edge port conf/oper
 P2P MAC Conf/Oper
Display the current P2P MAC conf/oper
Displa
y the current prot role
 Port Role
 Port State
Display the current port state
137
