Figure 4-6-16 MST Port Status page screenshot
The page includes the following fields:
Object Description
Displa
y the current MSTI ID.
 MSTI ID
The s
witch port number of the logical STP port.
 Port
Displa
y the current indentifier (priority / port ID)
 Indentifier (Priority /
Port ID)
Displa
y the current internal path cost configuration / operation
 Internal Path Cost
Conf/Oper
 Regional Root Bridge
Display the current regional root bridget.
Displa
y the current internal root cost.
 Internal Root Cost
Displa
y the current designated bridge.
 Designated Bridge
Display t
he current internal path cost.
 Internal Path Cost
Displa
y the current port role.
 Port Role
Displa
y the current port state.
 Port State
