User’s Manual of GSD-1002M
Figure 4-8-22 Properites page screenshot
The page includes the following fields:
Object Description
ï‚· Voice VLAN State
Indicates the Voice VLAN mode operation. We must disable MSTP feature
before we enable Voice VLAN. It can avoid the conflict of ingress filter. Possible
modes are:
â– Enabled: Enable Voice VLAN mode operation.
â– Disabled: Disable Voice VLAN mode operation
ï‚· Voice VLAN ID
Indicates the Voice VLAN ID. It should be a unique VLAN ID in the system and
cannot equal each port PVID. It is conflict configuration if the value equal
management VID, MVR VID, PVID, etc.
The allowed range is 1 to 4095.
Select 802.1p
value for this drop down list.
ï‚· Remark CoS/802.1p
Enable or d
isable 802.1p remark.
ï‚· 1p remark
ï‚· Aging Time (30-65536
min)
The time after which a port is removed from the Voice VLAN when VoIP traffic is
no longer received on the port.
(\Default: 1440 minutes).
Buttons
: Click to apply changes.
188
