User’s Manual of GSD-1002M
Figure 4-9-46 Option82 Global Setting page screenshot
The page includes the following fields:
Object Description
Select port for this drop dow
n list.
 Port
Enable or d
isable option82 function on port.
 Enable
 Allow Untrusted
Select modes for this drop down list. The following modes are available:
 Drop
 Keep
 Replace
Buttons
: Click to apply changes.
Figure 4-9-47 Option82 Global Setting page screenshot
The page includes the following fields:
Object Description
The s
witch port number of the logical port.
 Port
Displa
y the current status
 Enable
Displa
y the current untrusted mode
 Allow Untrusted
229
