User’s Manual of GSD-1002M
Figure 4-9-62 IP Source Guard Static Binding Entry page screenshot
The page includes the following fields:
Object Description
Select port for this drop dow
n list.
 Port
Indicates the ID of this pa
rticular VLAN.
 VLAN ID
Source MAC address is a
llowed.
 MAC Address
Source IP ad
dress is allowed.
 IP Address
Buttons
: Click to add authentication list.
Figure 4-9-63 IP Source Guard Binding Table Status page screenshot
The page includes the following fields:
Object Description
Displa
y the current port
 Port
Displa
y the current VLAN
 VLAN ID
Displa
y the current MAC address
 MAC Address
Displa
y the current IP Address
 IP Address
Displa
y the current entry type
 Type
Displa
y the current lease time
 Lease Time
 Action
Click
to delete IP source guard binding table status entry.
239
