User’s Manual of GSD-1002M
The page includes the following fields:
Object Description
 Mode
Indicates the IP address mode operation. Possible modes are:
Static: Enable NTP mode operation.
When enable NTP mode operation, the agent forward and to transfer NTP
messages between the clients and the server when they are not on the
same subnet domain.
DHCP: Enable DHCP client mode operation.
Enable the DHCP client by checking this box. If DHCP fails and the
configured IP address is zero, DHCP will retry. If DHCP fails and the
configured IP address is non-zero, DHCP will stop and the configured IP
settings will be used. The DHCP client will announce the configured
System Name as hostname to provide DNS lookup.
Provide the IP
address of this switch in dotted decimal notation.
 IP Address
Provide the su
bnet mask of this switch dotted decimal notation.
 Subnet Mask
Provide the IP
address of the router in dotted decimal notation.
 Gateway
Provide the IP
address of the DNS Server in dotted decimal notation.
 DNS Server 1/2
Buttons
: Click to apply changes.
Figure 4-2-3 IP Information page screenshot
The page includes the following fields:
Object Description
Displa
y the current DHCP state.
 DHCP State
 IP Address
Display the current IP address.
39
