User’s Manual of GSD-1002M
last characters must not be a dot or a dash.
Indicates the SNMP trap destination IPv6 address. IPv6 address is in 128-bit
records represented as eight fields of up to four hexadecimal digits with a colon
separating each field (:). For example, 'fe80::215:c5ff:fe03:4dc7'. The symbol '::'
is a special syntax that can be used as a shorthand way of representing multiple
16-bit groups of contiguous zeros; but it can appear only once. It can also
represent a legally valid IPv4 address. For example, '::192.1.2.34'.
Set the notify
type in traps or informs.
 Notify Type
Indicates the u
ser string when send SNMP trap packet.
 User Name
Indicates the SN
MP trap destination port. SNMP Agent will send SNMP message
via this port, the port range is 1~65535.
 UDP Port
Indicates the SNMP trap inform timeout. The allowed range is 1 to 300.
 Time Out
Indicates the SNMP trap inform retry times. The allowed range is 1 to 255.
 Retries
Buttons
: Click to add a new SNMPv3 host entry.
Figure 4-2-34 SNMPv3 Host Status page screenshot
The page includes the following fields:
Object Description
Displa
y the current server address.
 Server Address
Displa
y the current notify type.
 Notify Type
Displa
y the current user name.
 User Name
Displa
y the current UDP port.
 UDP Port
Displa
y the current time out.
 Time Out
Displa
y the current retry times.
 Retries
 Action
: Delete the SNMPv3 host entry.
63
