User’s Manual of GSD-1002M
Figure 4-4-5 LAG Management page screenshot
The page includes the following fields:
Object Description
Select LAG number for this dr
op down list.
ï‚· LAG
Indicates the p
er LAG name.
ï‚· Name
ï‚· Type
Indicates the trunk type.
Static: Force aggregared selected ports to be a trunk group.
LACP: LACP LAG negotiate Aggregated Port links with other LACP ports located
on a different device. If the other device ports are also LACP ports, the devices
establish a LAG between them.
Select port nu
mber for this drop down list to esatablish Link Aggregation.
ï‚· Ports
Figure 4-4-6 LAG Management Information page screenshot
The page includes the following fields:
Object Description
The LAG for
the settings contained in the same row.
ï‚· LAG
ï‚· Name
Display the current name
89
