User’s Manual of GSD-1002M
Figure 4-4-11 LACP Port Setting page screenshot
The page includes the following fields:
Object Description
Select port number for this drop dow
n list to set LACP port setting.
 Port Select
 Priority
The Prio controls the priority of the port.
If the LACP partner wants to form a larger group than is supported by this device
then this parameter will control which ports will be active and which ports will be
in a backup role.
Lower number means greater priority.
 Timeout
The Timeout controls the period between BPDU transmissions.
Short will transmit LACP packets each second, while Long will wait for 30
seconds before sending a LACP packet.
Buttons
: Click to apply changes.
Figure 4-4-12 LACP Port Information page screenshot
93
