User’s Manual of IGS-10020MT
4.8.2 IGMP Snooping Configuration
This page provides IGMP Snooping related configuration. The IGMP Snooping Configuration screen in Figure 4-8-5 appears.
Figure 4-8-5: IGMP Snooping Configuration Page Screenshot
The page includes the following fields:
Object Description
 Snooping Enabled
Enable the Global IGMP Snooping.
 Unregistered IPMCv4
Flooding enabled
Enable unregistered IPMCv4 traffic flooding.
 IGMP SSM Range
SSM (Source-Specific Multicast) Range allows the SSM-aware hosts and routers
run the SSM service model for the groups in the address range.
 Leave Proxy Enable
Enable IGMP Leave Proxy. This feature can be used to avoid forwarding
unnecessary leave messages to the router side.
 Proxy Enable
Enable IGMP Proxy. This feature can be used to avoid forwarding unnecessary
join and leave messages to the router side.
 Router Port
Specify which ports act as router ports. A router port is a port on the Ethernet
switch that leads towards the Layer 3 multicast device or IGMP querier.
169
