User’s Manual of IGS-10020MT
Default Setting:
disable
Example:
To show the log server mode:
IGS-10020MT:/>System log server mode
System Log Server Mode : Disabled
System Name
Description:
Set or show the system name.
Syntax:
System Name [<name>] [clear]
Parameters:
<name>: System name string. (1-255)
Use 'clear' or "" to clear the string
System name is a text string drawn from the alphabet (A-Za-z), digits (0-9), minus sign (-).
In CLI, no blank or space characters are permitted as part of a name.
The first character must be an alpha character, and the first or last character must not be a minus sign.
clear : Clear system name
Example:
To set device title:
IGS-10020MT:/>System name :IGS-10020MT
System Contact
Description:
Set or show the system contact.
Syntax:
System Contact [<contact>] [clear]
342

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
