Planet IGS-10020MT User Manual

User’s Manual of IGS-10020MT
374
VLAN Lookup
Description:
Lookup VLAN entry.
Syntax:
VLAN Lookup [<vid>] [(name <name>)] [combined|static|nas|mvr|voice_vlan|all]
Parameters:
<vid> : VLAN ID (1-4095), default: Show all VLANs
name : VLAN name string
<name>: VLAN name - Maximum of 32 characters. VLAN Name can only contain alphabets or numbers.
VLAN name should contain atleast one alphabet.
combined : Shows All the Combined VLAN database
static : Shows the VLAN entries configured by the administrator
nas : Shows the VLANs configured by NAS
mvr : Shows the VLANs configured by MVR
voice_vlan : Shows the VLANs configured by Voice VLAN
all : Shows all VLANs configuration
(default: combined VLAN Users configuration)
Example:
Show VLAN status
IGS-10020MT:/>vlan lookup
VID VLAN Name Ports
---- -------------------------------- -----
1 default 1-10
VLAN Name Add
Description:
Add VLAN Name to a VLAN ID Mapping.
Syntax:
VLAN Name Add <name> <vid>

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
