User’s Manual of IGS-10020MT
QoS Class
The Configuration All with available values will assign to whole DSCP values.
QoS Class value can be any of (0-7)
DPL
The Configuration All with available values will assign to whole DSCP values.
Drop Precedence Level (0-1)
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.9.9 DSCP Translation
This page allows you to configure the basic QoS DSCP Translation settings for all switches. DSCP translation can be done in
Ingress or Egress. The DSCP Translation screen in Figure 4-9-11 appears.
200
