User’s Manual of IGS-10020MT
313
4.14.6 Port Statistics
This page provides an overview of all LLDP traffic. Two types of counters are shown. Global counters are counters that refer to
the whole stack, switch, while local counters refer to counters for the currently selected switch. The LLDP Statistics screen in
Figure 4-14-5 appears.
Figure 4-14-5: LLDP Statistics Page Screenshot
The page includes the following fields:
Global Counters
Object Description
 Neighbor entries were
last changed at
It also shows the time when the last entry was last deleted or added. It also
shows the time elapsed since the last change was detected.
 Total Neighbors
Entries Added
Shows the number of new entries added since switch reboot.
 Total Neighbors
Entries Deleted
Shows the number of new entries deleted since switch reboot.
 Total Neighbors
Entries Dropped
Shows the number of LLDP frames dropped due to that the entry table was full.
 Total Neighbors
Entries Aged Out
Shows the number of entries deleted due to Time-To-Live expiring.

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
