Planet IGS-10020MT User Manual

User’s Manual of IGS-10020MT
Default Setting:
20
Example:
Set STP maximum hops in 25
IGS-10020MT:/>stp maxhops 25
STP MaxAge
Description:
Set or show the bridge instance maximum age.
Syntax:
STP MaxAge [<max_age>]
Parameters:
<max_age>: STP maximum age time (6-40, and max_age <= (forward_delay-1)*2)
Default Setting:
20
Example:
Set STP maximum age time in 10
IGS-10020MT:/>stp maxage 10
STP FwdDelay
Description:
Set or show the CIST/MSTI bridge forward delay.
Syntax:
STP FwdDelay [<delay>]
Parameters:
<delay>: MSTP forward delay (4-30, and max_age <= (forward_delay-1)*2))
Default Setting:
15
448

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
