Planet IGS-10020MT User Manual

User’s Manual of IGS-10020MT
Voice VLAN OUI Lookup
Description:
Clear Voice VLAN OUI entry. Modify OUI table will restart auto detect OUI process.
Syntax:
Voice VLAN OUI Clear
Example:
Lookup Voice VLAN OUI entry.
IGS-10020MT:/>voice vlan oui lookup
Voice VLAN Port Mode
Description:
Set or show the Voice VLAN port mode.
When the port mode isn't disabled, we must disable MSTP feature before we enable Voice VLAN. It can avoid the conflict
of ingress filter.
Syntax:
Voice VLAN Port Mode [<port_list>] [disable|auto|force]
Parameters:
<port_list>: Port list or 'all', default: All ports
disable : Disjoin from Voice VLAN.
auto : Enable auto detect mode. It detects whether there is VoIP phone attached on the specific port and configure the
Voice VLAN members automatically.
force : Forced join to Voice VLAN.
(default: Show Voice VLAN port mode)
Default Setting:
disable
Example:
Set auto mode for port 1-4 of Voice VLAN port mode.
IGS-10020MT:/>voice vlan port mode 1-4 auto
516

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
