Planet IGS-10020MT User Manual

User’s Manual of IGS-10020MT
8. TROUBLE SHOOTING
This chapter contains information to help you solve problems. If the Industrial Managed Switch is not functioning properly,
make sure the Ethernet Switch was set up according to instructions in this manual.
The per port LED is not lit
Solution:
Check the cable connection of the Industrial Managed Switch.
Performance is bad
Solution:
Check the speed duplex mode of the partner device. The Industrial Managed Switch is run at Auto-negotiation mode and
if the partner is set to half duplex, then the performance will be poor.
Per port LED is lit, but the traffic is irregular
Solution:
Check that the attached device is not set to dedicate full duplex. Some devices use a physical or software switch to change
duplex modes. Auto-negotiation may not recognize this type of full-duplex setting.
Why the Industrial Managed Switch doesn’t connect to the network
Solution:
Check per port LED on the Industrial Managed Switch. Try another port on the Industrial Managed Switch Make sure
the cable is installed properly Make sure the cable is the right type Turn off the power. After a while, turn on power again.
Can I install MGB-SX or other non wide temperature SFP module into SFP slot of Industrial Managed Switch?
Solution:
Yes, it does. However, since the MGB-SX and other non wide temperature SFP module cannot operate under -40 to 75
Degree C. Please pay attention to this point and consider use PLANET wide temperature SFP module for Industrial
Managed Switch.
541

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
