User’s Manual of IGS-10020MT
2.1.3 LED Indicators
 System
LED Color Function
P1 Green
Indicate the power 1 has power.
P2 Green
Indicate the power 2 has power.
Fault Green
Indicate the either power 1 or power 2 has no power.
 Per 10/100/1000Base-T Port
LED Color Function
Light
Indicate the link through that port is successfully established.
LNK / ACT Green
Blink
Indicate that the Switch is actively sending or receiving data
over that port.
Light
Indicate that the port is successfully connecting to the
network at 1000Mbps.
1000 Orange
Off
Indicate that the port is successfully connecting to the
network at 10Mbps or 100Mbps.
 Per SFP Interface
LED Color Function
Light
Indicate the link through that port is successfully established.
LNK / ACT Green
Blink
Indicate that the Switch is actively sending or receiving data
over that port.
Light
Indicate that the port is successfully connecting to the
network at 1000Mbps.
1000 Orange
Off
Indicate that the port is successfully connecting to the
network at 100Mbps.
31

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
