User’s Manual of IGS-10020MT
Parameters:
<port_list>: Port list or 'all', default: All ports
enable : Enable LLDP reception and transmission
disable: Disable LLDP
rx : Enable LLDP reception only
tx : Enable LLDP transmission only
(default: Show LLDP mode)
Default Setting:
disable
Example:
Enable port1 LLDP function.
IGS-10020MT:/>lldp mode 1 enable
LLDP Optional TLV
Description:
Show or Set LLDP Optional TLVs.
Syntax:
LLDP Optional_TLV [<port_list>] [port_descr|sys_name|sys_descr|sys_capa|mgmt_addr] [enable|disable]
Parameters:
<port_list>: Port list or 'all', default: All ports
port_descr : Description of the port
sysm_name : System name
sys_descr : Description of the system
sys_capa : System capabilities
mgmt_addr : Master's IP address
(default: Show optional TLV's configuration)
enable : Enables TLV
disable : Disable TLV
(default: Show optional TLV's configuration)
Default Setting:
Description of the port: Enable
System name: Enable
Description of the system: Enable
467

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Planet IGS-10020MT and is the answer not in the manual?

Planet IGS-10020MT Specifications

General IconGeneral
Switch typeManaged
Switch layerL2+
Quality of Service (QoS) supportYes
SFP module slots quantity2
Installed SFP modules quantity0
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity8
10G supportNo
Number of VLANs255
Networking standardsIEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms802.1x RADIUS, SSH, SSL/TLS
Throughput14.8 Mpps
Jumbo frames9000
MAC address table8000 entries
Stackable-
CertificationFCC Part 15 Class A, CE
Product colorBlack
Housing materialAluminum
International Protection (IP) codeIP30
Power consumption (typical)10 W
Heat dissipation34 BTU/h
Operating temperature (T-T)-40 - 75 °C
Operating relative humidity (H-H)5 - 95 %
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth87.8 mm
Width56 mm
Height135 mm
Weight720 g
