Planet IGS-10020MT User Manual

User’s Manual of IGS-10020MT
1.4 Product Features
 Physical Port
 8-Port 10/100/1000Base-T RJ-45 copper
 2 100/1000Base-X mini-GBIC/SFP slots, SFP type auto detection
 Industrial Case / Installation
 IP30 Aluminum case protection
 DIN-Rail and Wall Mount Design
 Redundant Power Design
-12 to 48V DC, redundant power with polarity reverse protect function
- AC 24V power adapter acceptable
 Supports EFT protection 6000 VDC for power line
 Supports 6000 VDC Ethernet ESD protection
 -40 to 75 Degree C operation temperature
 Layer 2 Features
 Prevents packet loss with back pressure (Half-Duplex) and IEEE 802.3x PAUSE frame flow control (Full-Duplex)
 High performance of Store-and-Forward architecture and runt/CRC filtering eliminates erroneous packets to optimize
the network bandwidth
 Storm Control support:
 Multicast / Unknown-Unicast
 Support VLAN
 IEEE 802.1Q Tagged VLAN
 Up to 255 VLANs groups, out of 4095 VLAN IDs
 Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
 Private VLAN Edge (PVE)
 Protocol-based VLAN
 MAC-based VLAN
 Voice VLAN
 Support Spanning Tree Protocol
 STP, IEEE 802.1D Spanning Tree Protocol
 RSTP, IEEE 802.1w Rapid Spanning Tree Protocol
 MSTP, IEEE 802.1s Multiple Spanning Tree Protocol, spanning tree by VLAN
 BPDU Guard
 Support Link Aggregation
 802.3ad Link Aggregation Control Protocol (LACP)
 Cisco ether-channel (Static Trunk)
 Maximum 5 trunk groups, up to 10 ports per trunk group
 Up to 20Gbps bandwidth(Duplex Mode)
 Provide Port Mirror (many-to-1)
 Port Mirroring to monitor the incoming or outgoing traffic on a particular port
 Quality of Service
 Ingress Shaper and Egress Rate Limit per port bandwidth control
 8 priority queues on all switch ports
23

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
