User’s Manual of IGS-10020MT
Example:
Set the port schedule mode in weighted mode
IGS-10020MT:/>qos Port Scheduler Mode 1-10 weighted
QoS Port Scheduler Weight
Description:
Set or show the port scheduler weight.
Syntax:
QoS Port Scheduler Weight [<port_list>] [<queue_list>] [<weight>]
Parameters:
<port_list> : Port list or 'all', default: All ports
<queue_list>: Weighted queue list or 'all', default: All weighted queues (0-5)
<weight> : Scheduler weight (1-100)
QoS Port QueueShaper Mode
Description:
Set or show the port queue shaper mode.
Syntax:
QoS Port QueueShaper Mode [<port_list>] [<queue_list>] [enable|disable]
Parameters:
<port_list> : Port list or 'all', default: All ports
<queue_list>: Queue list or 'all', default: All queues (0-7)
enable : Enable port queue shaper
disable : Disable port queue shaper
(default: Show port queue shaper mode)
Default Setting:
disable
Example:
Enable port queue shaper for all port & queue
IGS-10020MT:/>qos Port QueueShaper Mode 1-10 0-7 enable
487

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
