User’s Manual of IGS-10020MT
4.9.8 DSCP-Based QoS
This page allows you to configure the basic QoS DSCP based QoS Ingress Classification settings for all switches. The
DSCP-Based QoS screen in Figure 4-9-10 appears.
Figure 4-9-10: DSCP-Based QoS Ingress Classification Page Screenshot
The page includes the following fields:
Object Description
 DSCP
Maximum number of support ed DSCP values are 63.
 Trust
Click to check if the DSCP value is trusted.
* means to select all ports of
Industrial Managed Switch.
199
