Planet IGS-10020MT User Manual

User’s Manual of IGS-10020MT
MVR Port Mode
Description:
Set or show the MVR port mode.
Syntax:
MVR Port Mode [<port_list>] [enable|disable]
Parameters:
<port_list>: Port list or 'all', default: All ports
enable : Enable MVR mode
disable : Disable MVR mode
(default: Show MVR mode)
Default Setting:
disable
Example:
Enable the MVR port mode for port 1-4.
IGS-10020MT:/>mvr port mode 1-4 enable
MVR Multicast VLAN
Description:
Set or show MVR multicast VLAN ID.
Syntax:
MVR Multicast VLAN [<vid>]
Parameters:
<vid>: VLAN ID (1-4095), default: Show current MVR multicast VLAN ID
Default Setting:
100
Example:
Set VLAN 1000 for MVR multicast VLAN ID.
IGS-10020MT:/>mvr multicast vlan 1000
509

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
