Planet IGS-10020MT User Manual

User’s Manual of IGS-10020MT
513
Example:
Enable the Voice VLAN mode.
IGS-10020MT:/>voice vlan mode enable
Voice VLAN ID
Description:
Set or show Voice VLAN ID.
Syntax:
Voice VLAN ID [<vid>]
Parameters:
<vid>: VLAN ID (1-4095)
Default Setting:
1000
Example:
Set ID 2 for Voice VLAN ID.
IGS-10020MT:/>voice vlan id 2
Voice VLAN Agetime
Description:
Set or show Voice VLAN age time.
Syntax:
Voice VLAN Agetime [<age_time>]
Parameters:
<age_time>: MAC address age time (10-10000000) default: Show age time
Default Setting:
86400sec

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
