User’s Manual of IGS-10020MT
All means all ports will have one specific setting.
Counter
Counts the number of frames that match this ACE.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
: Click to refresh the page; any changes made locally will be undone.
: Click to clear the counters.
4.10.5 ACL Rate Limiter Configuration
Configure the rate limiter for the ACL of the switch.
The ACL Rate Limiter Configuration screen in Figure 4-10-5 appears.
Figure 4-10-5: ACL Rate Limiter Configuration Page Screenshot
228
