User’s Manual of IGS-10020MT
The page includes the following fields:
Object Description
 Port
The logical port for the settings contained in the same row.
 Policy ID
Select the policy to apply to this port. The allowed values are 1 through 8. The
default value is 1.
 Action
Select whether forwarding is permitted ("Permit") or denied ("Deny"). The default
value is "Permit". All means all ports will have one specific setting.
 Rate Limiter ID
Select which rate limiter to apply to this port. The allowed values are Disabled
or the values 1 through 15. The default value is "Disabled". All means all ports
will have one specific setting.
 EVC Policer
Select whether EVC policer is enabled or disabled. The default value is
"Disabled". All means all ports will have one specific setting.
 EVC Policer ID
Select which EVC policer ID to apply on this port. The allowed values are
Disabled or the values 1 through 128.
 Port Redirect
Select which port frames are redirected on. The allowed values are Disabled or
a specific port number. The default value is "Disabled". All means all ports will
have one specific setting.
 Mirror
Specify the mirror operation of this port. The allowed values are:
Enabled: Frames received on the port are mirrored.
Disabled: Frames received on the port are not mirrored.
The default value is "Disabled".
All means all ports will have one specific setting.
 Logging
Specify the logging operation of this port. The allowed values are:
Enabled: Frames received on the port are stored in the System Log.
Disabled: Frames received on the port are not logged.
The default value is "Disabled".
Please note that the System Log memory size and logging rate is limited.
All means all ports will have one specific setting.
 Shutdown
Specify the port shut down operation of this port. The allowed values are:
Enabled: If a frame is received on the port, the port will be disabled.
Disabled: Port shut down is disabled.
The default value is "Disabled".
All means all ports will have one specific setting.
 State
Specify the port state of this port. The allowed values are:
Enabled: To reopen ports by changing the volatile port configuration of the ACL
user module.
Disabled: To close ports by changing the volatile port configuration of the ACL
user module.
The default value is "Enabled".
227

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
