User’s Manual of IGS-10020MT
26
1.5 Product Specification
Model Name IGS-10020MT
Hardware Specification
Copper Ports 8 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports
SFP/mini-GBIC Slots
2 1000Base-SX/LX/BX SFP interfaces (Port-9 and Port-10)
Compatible with 100Base-FX SFP
Switch Architecture Store-and-Forward
Switch Fabric 20Gbps / non-blocking
Throughput (packet per second) 14.8Mpps
Address Table 8K entries, automatic source address learning and ageing
Share data Buffer 512 kilobytes
Flow Control IEEE 802.3x Pause Frame for Full-Duplex. Back pressure for Half-Duplex
Jumbo Frame 9Kbytes
Reset Button
< 5 sec: System reboot
> 5 sec: Factory Default
ESD Protection 6KV DC
EFT Protection 6KV DC
Enclosure IP30 Aluminum Metal Case
Installation DIN Rail Kit and Wall Mount Kit
Alarm One relay output for power fail. Alarm Relay current carry ability: 1A @ DC 24V
LED Indicator
System:
Power 1 (Green)
Power 2 (Green)
Fault Alarm (Green)
Per 10/100/1000T RJ-45 Ports:
LNK/ACT (Green)
1000 (Orange)
Per SFP Interface:
LNK/ACT (Green)
1000 (Orange)
Dimension (W x D x H) 87.8 x 135 x 56mm
Weight 720g
Power Requirement DC 12 to 48V. AC 24V Power Adapter
Power Consumption 10 Watts / 34BTU (Full loading)
Layer 2 function
Basic Management Interfaces Web Browser, Remote Telnet, SNMPv1, v2c
Secure Management Interface SSH, SSL, SNMP v3
Port configuration
Port disable/enable
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection
Flow Control disable / enable
Power saving mode control
Port Status
Display each port’s speed duplex mode, link status, Flow control status. Auto
negotiation status, trunk status.
Port Mirroring
TX / RX / Both
Many to 1 monitor
VLAN
802.1Q Tagged Based VLAN ,up to 255 VLAN groups
Q-in-Q tunneling
Private VLAN Edge (PVE)
MAC-based VLAN
Protocol-based VLAN
Voice VLAN
MVR (Multicast VLAN Registration)
Up to 255 VLAN groups, out of 4095 VLAN IDs
Link Aggregation
IEEE 802.3ad LACP / Static Trunk
Support 5 groups of 10-Port trunk support
QoS Traffic classification based, Strict priority and WRR

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
