User’s Manual of IGS-10020MT
Default Setting:
Auto
Example:
Set secure learning mode in port1
IGS-10020MT:/>mac learning 1 secure
MAC Dump
Description:
Show sorted list of MAC address entries.
Syntax:
MAC Dump [<mac_max>] [<mac_addr>] [<vid>]
Parameters:
<mac_max> : Maximum number of MAC addresses 1-8192, default: Show all addresses
<mac_addr>: First MAC address (xx-xx-xx-xx-xx-xx), default: MAC address zero
<vid> : First VLAN ID (1-4095), default: 1
Example:
Show all of MAC table
IGS-10020MT:/>mac dump
Type VID MAC Address Ports
------ --- ----------------- -----
Static 1 00-30-00-33-22-55 1
Static 1 00-30-4f-24-04-d1 None,CPU
Static 1 33-33-ff-24-04-d1 None,CPU
Static 1 33-33-ff-a8-00-64 None,CPU
Dynamic 1 40-61-86-04-18-69 10
Static 1 ff-ff-ff-ff-ff-ff 1-24,CPU
MAC Statistics
Description:
Show MAC address table statistics.
365

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
