Planet IGS-10020MT User Manual

User’s Manual of IGS-10020MT
Syntax:
IPMC Flooding [mld|igmp] [enable|disable]
Parameters:
mld|igmp:
mld : IPMC for IPv6 MLD
igmp: IPMC for IPv4 IGMP
enable : Enable IPMC flooding
disable: Disable IPMC flooding
(default: Show global IPMC flooding mode)
Default Setting:
enable
Example:
Enable IGMP flooding
IGS-10020MT:/>ipmc flooding igmp enable
IPMC Leave Proxy
Description:
Set or show the mode of IPMC Leave Proxy.
Syntax:
IPMC Leave Proxy [mld|igmp] [enable|disable]
Parameters:
mld|igmp:
mld : IPMC for IPv6 MLD
igmp: IPMC for IPv4 IGMP
enable : Enable IPMC Leave Proxy
disable: Disable IPMC Leave Proxy
(default: Show global IPMC Leave Proxy mode)
Default Setting:
disable
Example:
Enable IGMP Leave Proxy
IGS-10020MT:/>ipmc leave proxy igmp enable
521

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
