User’s Manual of IGS-10020MT
187
4.8.17 MVR SFM Information
Entries in the MVR SFM Information Table are shown on this page. The MVR SFM (Source-Filtered Multicast) Information Table
also contains the SSM (Source-Specific Multicast) information. This table is sorted first by VLAN ID, then by group, and then by
Port. Different source addresses belong to the same group are treated as single entry.
The MVR Groups Information screen in Figure 4-8-20 appears.
Figure 4-8-20: MVR Groups Information Page Screenshot
The page includes the following fields:
Object Description
VLAN ID
VLAN ID of the group.
Group
Group ID of the group displayed.
Port
Switch port number.
Mode
Indicates the filtering mode maintained per (VLAN ID, port number, Group
Address) basis. It can be either Include or Exclude.
Source Address
IP Address of the source. Currently, system limits the total number of IP source
addresses for filtering to be 128. When there is no any source filtering address,
the text "None" is shown in the Source Address field.
Type
Indicates the Type. It can be either Allow or Deny.
Hardware Filter /
Switch
Indicates whether data plane destined to the specific group address from the
source IPv6 address could be handled by chip or not.
Buttons
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the page immediate
: Updates the table starting from the first entry in the MVR SFM Information Table.
: Updates the table, starting with the entry after the last entry currently displayed.
