User’s Manual of IGS-10020MT
Example:
Add 00-11-22-33-44-55-66 in VLAN 20 for all port
IGS-10020MT:/>vcl macvlan add 00-11-22-33-44-55-66 20 1-10
VCL MAC-based VLAN Delete
Description:
Delete VCL MAC-based VLAN entry.
Syntax:
VCL Macvlan Del <mac_addr>
Parameters:
<mac_addr> : MAC address (xx-xx-xx-xx-xx-xx)
Example:
Delete 00-11-22-33-44-55-66 in MAC-based VLAN list
IGS-10020MT:/> vcl macvlan del 00-11-22-33-44-55-66
VCL Stasus
Description:
Show VCL MAC-based VLAN users configuration.
Syntax:
VCL Status [combined|static|nas|all]
Parameters:
combined|static|nas|all: VCL User
VCL Protocol-based VLAN Add Ethernet II
Description:
Add VCL protocol-based VLAN Ethernet-II protocol to group mapping.
Syntax:
VCL ProtoVlan Protocol Add Eth2 <ether_type>|arp|ip|ipx|at <group_id>
531

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
