Planet IGS-10020MT User Manual

User’s Manual of IGS-10020MT
1. Any
2. Ethernet
3. LLC
4. SNAP
5. IPv4
6. IPv6
Note: All frame types are explained below.
 Any
Allow all types of frames.
 Ethernet
Ethernet Type Valid ethernet type can have value within 0x600-0xFFFF or 'Any'
but excluding 0x800(IPv4) and 0x86DD(IPv6), default value is 'Any'.
 LLC
SSAP Address Valid SSAP(Source Service Access Point) can vary from 0x00 to
0xFF or 'Any', the default value is 'Any'
DSAP Address Valid DSAP(Destination Service Access Point) can vary from
0x00 to 0xFF or 'Any', the default value is 'Any'
Control Address Valid Control Address can vary from 0x00 to 0xFF or 'Any', the
default value is 'Any'
 SNAP
PID Valid PID(a.k.a ethernet type) can have value within 0x00-0xFFFF or 'Any',
default value is 'Any'
 IPv4
Protocol IP protocol number: (0-255, TCP or UDP) or 'Any'
Source IP Specific Source IP address in value/mask format or 'Any'. IP and Mask
are in the format x.y.z.w where x, y, z, and w are decimal numbers between 0 and
255. When Mask is converted to a 32-bit binary string and read from left to right,
all bits following the first zero must also be zero
DSCP Diffserv Code Point value(DSCP): It can be specific value, range of value
or 'Any'. DSCP values are in the range 0-63 including BE, CS1-CS7, EF or
AF11-AF43
IP Fragment IPv4 frame fragmented option: yes|no|any
Sport Source TCP/UDP port:(0-65535) or 'Any', specific or port range applicable
for IP protocol UDP/TCP
Dport Destination TCP/UDP port:(0-65535) or 'Any', specific or port range
applicable for IP protocol UDP/TCP
 IPv6
Protocol IP protocol number: (0-255, TCP or UDP) or 'Any'
Source IP IPv6 source address: (a.b.c.d) or 'Any', 32 LS bits
DSCP Diffserv Code Point value(DSCP): It can be specific value, range of value
or 'Any'. DSCP values are in the range 0-63 including BE, CS1-CS7, EF or
AF11-AF43
Sport Source TCP/UDP port:(0-65535) or 'Any', specific or port range applicable
for IP protocol UDP/TCP
206

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
