Page #238 background imageLoading...
Page #238 background image
User’s Manual of IGS-10020MT
the entry.
Hold Time
This setting applies to the following modes, i.e. modes using the Port Security
functionality to secure MAC addresses:
Single 802.1X
Multi 802.1X
MAC-Based Auth.
If a client is denied access - either because the RADIUS server denies the client
access or because the RADIUS server request times out (according to the
timeout specified on the "ConfigurationSecurityAAA" page) - the client is put
on hold in the Unauthorized state. The hold timer does not count during an
on-going authentication.
In MAC-based Auth. mode, the The switch will ignore new frames coming from
the client during the hold time.
The Hold Time can be set to a number between 10 and 1000000 seconds.
RADIUS-Assigned QoS
Enabled
RADIUS-assigned QoS provides a means to centrally control the traffic class to
which traffic coming from a successfully authenticated supplicant is assigned on
the switch. The RADIUS server must be configured to transmit special RADIUS
attributes to take advantage of this feature (see RADIUS-Assigned QoS Enabled
bel
o
w for a detailed description).
The "RADIUS-Assigned QoS Enabled" checkbox provides a quick way to
globally enable/disable RADIUS-server assigned QoS Class functionality. When
checked, the individual ports' ditto setting determine whether RADIUS-assigned
QoS Class is enabled for that port. When unchecked, RADIUS-server assigned
QoS Class is disabled for all ports.
RADIUS-Assigned
VLAN Enabled
RADIUS-assigned VLAN provides a means to centrally control the VLAN on
which a successfully authenticated supplicant is placed on the switch. Incoming
traffic will be classified to and switched on the RADIUS-assigned VLAN. The
RADIUS server must be configured to transmit special RADIUS attributes to take
advantage of this feature (see RADIUS-Assigned VLAN Enabled below for a
det
ail
ed description).
The "RADIUS-Assigned VLAN Enabled" checkbox provides a quick way to
globally enable/disable RADIUS-server assigned VLAN functionality. When
checked, the individual ports' ditto setting determine whether RADIUS-assigned
VLAN is enabled for that port. When unchecked, RADIUS-server assigned VLAN
is disabled for all ports.
Guest VLAN Enabled
A Guest VLAN is a special VLAN - typically with limited network access - on
which 802.1X-unaware clients are placed after a network administrator-defined
timeout. The switch follows a set of rules for entering and leaving the Guest
238
