User’s Manual of IGS-10020MT
MAC-based:
Counts all the backend server
packets sent from the switch
towards the backend server
for a given port (left-most
table) or client (right-most
table). Possible
retransmissions are not
counted.
Information about the last supplicant/client that attempted to authenticate. This
information is available for the following administrative states:
Port-based 802.1X
Single 802.1X
Multi 802.1X
MAC-based Auth.
Name IEEE Name Description
MAC
Address
dot1xAuthLastEapolF
rameSource
The MAC address of the last supplicant/client.
VLAN ID
- The VLAN ID on which the last frame from the
last supplicant/client was received.
Version
dot1xAuthLastEapolF
rameVersion
802.1X-based:
The protocol version number carried in the most
recently received EAPOL frame.
MAC-based:
Not applicable.
 Last Supplicant/Client
Info
Identity
-
802.1X-based:
The user name (supplicant identity) carried in the
most recently received Response Identity
EAPOL frame.
MAC-based:
Not applicable.
251

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
