Planet IGS-10020MT User Manual

User’s Manual of IGS-10020MT
RADIUS Acc
ounting Server Configuration
The table has one row for each RADIUS Accounting Server and a number of columns, which are:
Object Description
 #
The RADIUS Accounting Server number for which the configuration below
applies.
 Enabled
Enable the RADIUS Accounting Server by checking this box.
 IP Address/Hostname
The IP address or hostname of the RADIUS Accounting Server. IP address is
expressed in dotted decimal notation.
 Port
The UDP port to use on the RADIUS Accounting Server. If the port is set to 0
(zero), the defau
lt port (1813) is used on the RADIUS Accounting Server.
 Secret
The secret - up to 29 characters long - shared between the RADIUS Accounting
Server and the switch.
TACACS+ Authentication Server Configuration
The table has one row for each TACACS+ Authentication Server and a number of columns, which are:
Object Description
 #
The TACACS+ Authentication Server number for which the configuration below
applies.
 Enabled
Enable the TACACS+ Authentication Server by checking this box.
 IP Address/Hostname
The IP address or hostname of the TACACS+ Authentication Server. IP address
is expressed in dotted decimal notation.
 Port
The TCP port to use on the TACACS+ Authentication Serv
er. If the port is set to 0
(zero), the default port (49) is used on the TACACS+ Authentication Server.
 Secret
The secret - up to 29 characters long - shared between the TACACS+
Authentication Server and the switch.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
256

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
