Planet IGS-10020MT User Manual

User’s Manual of IGS-10020MT
The page includes the following fields:
RADIUS Authentication Servers
The statistics map closely to those specified in RFC4668 - RADIUS Authentication Client MIB.
Use the server select box to switch between the backend servers to show details for.
Object Description
RADIUS authentication server packet counter. There are seven receive and four
transmit counters.
Direction Name RFC4668 Name Description
Rx
Access
Accepts
radiusAuthClientExtA
ccessAccepts
The number of RADIUS
Access-Accept packets (valid
or invalid) received from the
server.
Rx
Access Rejects
radiusAuthClientExtA
ccessRejects
The number of RADIUS
Access-Reject packets (valid
or invalid) received from the
server.
Rx
Access
Challenges
radiusAuthClientExtA
ccessChallenges
The number of RADIUS
Access-Challenge packets
(valid or invalid) received from
the server.
Rx
Malformed
Access
Responses
radiusAuthClientExt
MalformedAccessRe
sponses
The number of malformed
RADIUS Access-Response
packets received from the
server. Malformed packets
include packets with an invalid
length. Bad authenticators or
Message Authenticator
attributes or unknown types
are not included as malformed
access responses.
 Packet Counters
Rx
Bad
Authenticators
radiusAuthClientExtB
adAuthenticators
The number of RADIUS
Access-Response packets
containing invalid
authenticators or Message
Authenticator attributes
260

Planet IGS-10020MT Specifications

General

Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	255
Networking standards	IEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Throughput	14.8 Mpps
Jumbo frames	9000
MAC address table	8000 entries
Stackable	-
Certification	FCC Part 15 Class A, CE
Product color	Black
Housing material	Aluminum
International Protection (IP) code	IP30
Power consumption (typical)	10 W
Heat dissipation	34 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87.8 mm
Width	56 mm
Height	135 mm
Weight	720 g
