User’s Manual of IGS-10020MT
LLDP-MED
LLDP-MED is an extendsion of IEEE 802.1ab and is defined by the telecommunication industry association
(TIA-1057).
LOC
LOC is an acronym for Loss Of Connectivity and is detected by a MEP and is indicating lost connectivity in the network.
Can be used as a switch criteria by EPS
M
MAC Table
Switching of frames is based upon the DMAC address contained in the frame. The switch builds up a table that maps
MAC addresses to switch ports for knowing which ports the frames should go to ( based upon the DMAC address in
the frame ). This table contains both static and dynamic entries. The static entries are configured by the network
administrator if the administrator wants to do a fixed mapping between the DMAC address and switch ports.
The frames also contain a MAC address ( SMAC address ), which shows the MAC address of the equipment sending
the frame. The SMAC address is used by the switch to automatically update the MAC table with these dynamic MAC
addresses. Dynamic entries are removed from the MAC table if no frame with the corresponding SMAC address have
been seen after a configurable age time.
MEP
MEP is an acronym for Maintenance Entity Endpoint and is an endpoint in a Maintenance Entity Group (ITU-T Y.1731).
MD5
MD5 is an acronym for Message-Digest algorithm 5. MD5 is a message digest algorithm, used cryptographic hash
function with a 128-bit hash value. It was designed by Ron Rivest in 1991. MD5 is officially defined in RFC 1321 - The
MD5 Message-Digest Algorithm.
Mirroring
For debugging network problems or monitoring network traffic, the switch system can be configured to mirror frames
from multiple ports to a mirror port. (In this context, mirroring a frame is the same as copying the frame.)
Both incoming (source) and outgoing (destination) frames can be mirrored to the mirror port.
MLD
MLD is an acronym for M
ulticast Listener Discovery for IPv6. MLD is used by IPv6 routers to discover multicast
listeners on a directly attached link, much as IGMP is used in IPv4. The protocol is embedded in ICMPv6 instead of
using a separate protocol.
MVR
552

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Planet IGS-10020MT and is the answer not in the manual?

Planet IGS-10020MT Specifications

General IconGeneral
Switch typeManaged
Switch layerL2+
Quality of Service (QoS) supportYes
SFP module slots quantity2
Installed SFP modules quantity0
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity8
10G supportNo
Number of VLANs255
Networking standardsIEEE 1588, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology1000BASE-T, 100BASE-TX, 10BASE-T
Security algorithms802.1x RADIUS, SSH, SSL/TLS
Throughput14.8 Mpps
Jumbo frames9000
MAC address table8000 entries
Stackable-
CertificationFCC Part 15 Class A, CE
Product colorBlack
Housing materialAluminum
International Protection (IP) codeIP30
Power consumption (typical)10 W
Heat dissipation34 BTU/h
Operating temperature (T-T)-40 - 75 °C
Operating relative humidity (H-H)5 - 95 %
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth87.8 mm
Width56 mm
Height135 mm
Weight720 g
