VTrak M610i, M310i, M210i Product Manual
208
Figure 9. The M310i/M210i blower and its electrical connector
7. Attach the electrical connector of the new fan or blower and set the fan or
blower in place.
Be sure you position the fan or blower onto the mounting pins. See Figures
10 and 11.
Figure 10.Position the fan onto the mounting pins, pointed outward
Electrical connector Blower
