VTrak M610i, M310i, M210i Product Manual
212
Figure 14.Removing the cooling unit from the M610i
Figure 15.Removing the cooling unit from the M310i/M210i
3. Loosen the thumbscrew. A retainer keeps the thumbscrew in place.
4. Grasp the cover near the thumbscrews and lift it off. Remove the cover to
access the battery. See Figures 16 and 17.
Figure 16.Loosen the thumbscrews and remove the cover (M610i)
Loosen the thumbscrews
Lift the cover
