Quantum ODYSSEY HF Series User Manual

Chapter 3 Calibration
Revision W HF Series X-ray Generators - Service Manual
3-22 Quantum Medical Imaging, LLC
• Generator Timeout: Sets the delay time for generator to automatically
shut down if no keys are pressed on operator control panel (selectable in
30 minute increments between 0 minutes up to 180 minutes).
If "0" is
selected, the generator will not timeout, however, the filament will turn
off if one hour of inactivity.
• Date Format setting: Sets date/time format (options are "US" or
"International)
To change a setting, press the key next to the system setting you want to change.
After all system settings are set appropriately, press the key next to the Main
field. The system settings are saved in non-volatile random access memory
(NVRAM) and the system returns to the main Service Menu (see Figure 3-3).
The following paragraphs provide specific instructions for configuring each of the
above system settings.
Set Date Screen
The Set Date screen, shown below, displays the current date setting. To
change the date setting, proceed as follows:
Figure 3-17. Setting the Date
1. Adjust the month, date or year setting using the appropriate keys as
shown in Figure 3-17, above, until desired date is displayed.
2. To exit the screen and return to the Start Up Screen, press the key next
to the Main field.
USE
THESE
KEYS
TO SET
MONTH
USE THESE
KEYS TO
SET DAY
USE THESE
KEYS TO
SET YEAR
