Chapter 5 Service Instructions
Revision W HF Series X-ray Generators - Service Manual
5-88 Quantum Medical Imaging, LLC
5. Set the power on/standby switch on the Operator Control Panel
(OCP) to the on ( ) position.
6. Perform Rotor Drive Board adjustments as described in the "Rotor
Drive Board A10 (AY40-013T) Adjustment" procedure in Chapter
2, Assembly & Installation.
Standard AEC Control Board A11 (P/N AY40-031S) Removal
CAUTION! The AEC Control Drive Board contains
electrostatic sensitive devices. Observe proper
grounding precautions before handling the AEC
Control Drive Board or any other circuit board.
1. Set the power on/standby switch on the Operator Control Panel
(OCP) to the standby ( ) position.
2. Set the ON/OFF circuit breaker CB1 on the generator cabinet to
OFF position.
3. Tag and remove plugs connected to A11J1 and A11J4.
4. Disconnect any Wall and/or Table bucky cable(s) connected to
A11J2, A11J3, and A11J5.
5. Remove four (4) hex nuts securing AEC Control Board A11 to the
PCB Door and remove the AEC Control Board.
Standard AEC Control Board A11 (P/N AY40-031S) Replacement
CAUTION! The AEC Control Board contains elec-
trostatic sensitive devices. Observe proper
grounding precautions before handling the AEC
Control Drive Board or any other circuit board.
1. Place the new AEC Control Board A10 on the PCB Door and
secure using four (4) hex nuts.
2. Re-connect any Wall and/or Table bucky cable(s) to A11J2, A11J3
and A11J5 on AEC Control Board.
3. Re-connect plugs toA11J1 and A11J4 and remove tags.
4. Set the ON/OFF circuit breaker CB1 on the generator cabinet to
ON position.
5. Set the power on/standby switch on the Operator Control Panel
(OCP) to the on ( ) position.
6. Perform AEC calibration procedures (refer to Chapter 3, CALIBRA-
TION (ODYSSEY) or Appendix B (DiRex Integration generators),
or Appendix D (all other integrated generators).
