Quantum ODYSSEY HF Series User Manual

Chapter 3 Calibration
Revision W HF Series X-ray Generators - Service Manual
3-28 Quantum Medical Imaging, LLC
Generator Timeout Setting
The Service Settings Menu, shown below, displays the current automatic gen-
erator power shutdown setting. The time period selected represents the
amount of delay time, after which if no user activity is detected, the system
automatically enters Automatic Power Stand By mode. This mode is entered
to help reduce power consumption while protecting system electronics. To
set the generator time-out setting, proceed as follows:
Figure 3-23. Setting Generator Timeout Setting
Press the key next to the Generator Timeout field to scroll through avail-
able time period settings (0, 30, 60, 90, 120, 150, 180 minutes) until desired
setting is displayed. Note: Selecting "0" disables automatic timeout function.
Date/Time Format Setting
The Date Format field (see Figure 3-23) displays the current date/time format
setting. To change the date/time format setting, proceed as follows:
1. Press the key next to the Date Format field to select either "US" (e.g.,
JUN 11,01 2:00 pm) or Int’l (e.g., 11 JUN 01 14:00) date/time format
used for display of date and time on all applicable system screens.
2. To exit the screen and return to the Start Up Screen, press the key next
to the Main field
PRESS THIS
KEY TO
SELECT
GENERATOR
TIMEOUT
SETTING
PRESS THIS
KEY TO
SELECT
GENERATOR
TIMEOUT
SETTING
PRESS THIS
KEY TO
SELECT
GENERATOR
TIMEOUT
SETTING
PRESS THIS
KEY TO
SELECT DATE
FORMAT
